Kitronik Solar-Powered Garden Light – Includes Rechargeable Battery

Description

Build your own DIY “Sun Jar” with the Kitronik Solar Garden Light Kit, a sustainable energy project that illuminates a white LED using solar power.

The resin encapsulated solar panel is waterproof and charges a rechargeable AA battery during the day. When darkness falls, the circuit automatically switches from charging the battery to lighting the LED.

• Waterproof solar panel
• Automatic light activation when dark
• Custom enclosure friendly; fits into old jars

Contents include:

• 1 x Solar Cell (60mm by 60mm)
• 1 x Rechargeable Battery 1300mAh
• 1 x 22ohm Resistor
• 1 x 330ohm Resistor
• 1 x 1Kohm Resistor
• 1 x 10Kohm Resistor
• 1 x 100Kohm Resistor
• 2 x 1nF Ceramic Disc Capacitor
• 1 x Wide White 5mm Water Clear LED
• 2 x BC337 NPN Transistor
• 1 x AA Battery Holder, PCB Mounting
• 2 x 470uH Inductors
• 1 x BAT41 Diode
• 0.5m Connecting Wire (For Solar Cell)
• 1 x Solar Garden Light PCB

Dimensions: Length 56mm, Width 44mm.

Note: Requires soldering tools and wire cutters (sold separately).
