Description
Let your project know its place in the world with this tiny but ultra-sensitive global positioning breakout!
This I2C breakout features a PA1010D GPS receiver module with inbuilt ceramic antenna, allowing extraction of date, time, latitude, longitude, speed, and altitude data from satellites.
It includes a supercapacitor that acts like a short-term backup battery to enable quick satellite lock after power down. An indicator LED flashes whenever the module has a satellite fix.
Ideal for projects like weather stations or modular GPS navigation systems, this breakout is compatible with Raspberry Pi, Arduino, and CircuitPython.
Features
- PA1010D GPS / GLONASS / GALILEO receiver module with ceramic antenna and datasheet available
- Supports up to 210 PRN channels with 99 search channels and 33 simultaneous tracking channels
- Ultra-high sensitivity: -165dBm
- High accuracy 1-PPS timing support (±20ns jitter)
- Supercapacitor for maintaining satellite data and internal clock (approx. 1 hour capacity)
- Green LED indicator connected to PPS output; configurable via software
- 2x M2.5 mounting holes
- I2C interface, default address 0x10
- 3V to 5V compatible with reverse polarity protection
- Raspberry Pi-compatible pinout (pins 1, 3, 5, 7, 9)
- Compatible with Raspberry Pi, Arduino, and CircuitPython
- Python library and schematic available
Kit Includes
- PA1010D GPS Breakout
- 1×5 straight male header
- 1×5 right angle female header
Notes
- No external antenna connection available
- Default I2C address cannot be changed
- GALILEO satellite detection may require firmware update via soldering and flashing
- Dimensions approximately 28x21x9 mm (LxWxH)
