Description
The Kitronik Air Freshener Kit uses a silent low current motor to spin a fan, ideal for circulating air through an air freshener containing potpourri or moving a lightweight buggy. The electronics consume no power while on standby, and pressing the switch activates the motor for up to 100 seconds, with adjustable timing via the onboard variable resistor.
Features:
- Silent motor operation
- Adjustable timer up to 100 seconds
Kit Contents:
- Battery Holder With Leads (2x AA)
- 1K Resistor 5%
- 1M Resistor
- PCB Trimmer 1M POT
- 16V 220uF Electrolytic Capacitor
- 2x BC547 NPN Transistors
- Miniature Push to Make Switch, Red
- Low Inertia Solar Motor – 1820 RPM
- 55mm White Four Blade Miniature Impeller
- 0.5m Connecting Wire
- Air Freshener PCB
Dimensions:
- Length: 46mm
- Width: 28mm
Requirements:
- 2 x AA Batteries or 1 x Easy Build Coin Cell Power Board
- Soldering Iron and Solder
- Wire Cutters and Wire Strippers
