Description
The ESP32-C6-WROOM-1-N8 is an advanced ESP32-C6-based module designed for IoT applications. It supports WiFi 6 in the 2.4GHz band, Bluetooth® 5, Zigbee 3.0, and Thread, making it versatile for various wireless communication needs. This module is pin-to-pin compatible with the ESP32-WROOM series and features low power consumption for efficient operation.
Key Features:
- 32-bit RISC-V single-core processor operating at up to 160 MHz
- State-of-the-art power and RF performance
- 320 KB ROM, 512 KB SRAM, and 16 KB Low-power SRAM on the chip
- Works with external flash memory
- 30 (QFN40) or 22 (QFN32) programmable GPIOs supporting SPI, UART, I2C, I2S, RMT, TWAI, and PWM
Note: This product is intended for advanced users. It is just the module and requires soldering onto a board with supporting circuitry to be functional.
Technical Details:
- Product Dimensions: 25.5mm x 18.0mm x 3.2mm (1.0″ x 0.7″ x 0.1″)
