Description
The Smart Car Cutebot Robot is a fully-assembled, easy-to-use robot smart car designed for micro:bit and MakeCode. It requires no soldering or tools, simply insert your micro:bit into the top slot and add three AAA batteries to get moving.
This rear-drive smart car is powered by dual high-speed metal-geared N20 motors with rubber tires and includes an ultrasonic distance sensor to avoid collisions. It also features two RGB LED headlights, two underlights, two line-tracking light sensors, an active buzzer for beeps and tones, and headers for additional servos and sensors.
Features:
- Rear-drive high speed metal-geared N20 motors (300 RPM max) with rubber tires
- Compact, durable PCB body, crash-proof and easy to handle
- Only batteries and ultrasonic sensor require assembly, no soldering or tools needed
- Slot for ultrasonic distance sensor and I2C port for sensor add-ons on front edge
- Headers for additional servos and sensors on back edge
- Metal caster wheel for stability
- Flexible and fast movement
- Dual line-tracking light sensors
- Infrared sensor supports optional IR remote control
- Multiple rainbow LEDs (NeoPixels)
Technical Specifications:
- Working voltage: 3.5V~5V (3 x AAA batteries)
- Dimensions: 85 x 85 x 38 mm
- Buzzer piezo type connected on P0
- Additional 3-pin breakouts for P1 and P2
- Line-follower sensors on P13 and P14
- Infrared control on P16
- Headlights: 2 x RGB LEDs
- Rainbow LEDs: 2 x NeoPixels on P15
- I2C Connection on P19 and P20
- Motors: N20 metal-gear motor
- Ultrasonic sensor: HC-SR04+
Note: micro:bit and AAA batteries are not included.
For detailed tutorials and ready-to-go MakeCode examples, please visit the official tutorial website.
