Description
The BME690 is a super-smart Bosch sensor breakout that precisely measures temperature, pressure, and humidity. Additionally, it features an AI-enhanced gas scanner function for detecting volatile organic compounds (VOCs), volatile sulfur compounds (VSCs), carbon monoxide, and hydrogen, providing a comprehensive measure of indoor or outdoor air quality.
This sensor builds upon the BME6XX series with improvements such as lower power consumption and increased robustness in humid environments.
The breakout supports I2C communication with an adjustable address and is compatible with Raspberry Pi, Raspberry Pi Pico, and other RP2040 and RP2350 microcontrollers.
Features include:
- Bosch BME690 4-in-1 environmental sensor with AI-enhanced gas measurement
- I2C interface with selectable address via a cuttable ADDR trace (0x76 or 0x77)
- Qwiic/STEMMA QT connector for easy integration
- Compatible with 3.3V or 5V systems
- Reverse polarity protection on Breakout Garden connector
- Raspberry Pi-compatible pinout (pins 1, 3, 5, 7, 9)
- Software support with Python libraries for Raspberry Pi and C++/MicroPython libraries for RP2040 and RP2350
Kit includes:
- BME690 breakout board
- 1×5 pin header
- 1×5 right angle socket header for direct Raspberry Pi GPIO connection
Specifications:
- Dimensions: approx 19mm x 19mm x 5mm (L x W x H)
- Interfaces: I2C (0x76 or 0x77 address selectable)
- Compatible with Breakout Garden system and Qwiic/STEMMA QT cables
For further development, Bosch provides a C library and desktop analysis tools, while Pimoroni offers Python and MicroPython libraries for easy integration into your projects.
