Bilstein B8 41-314227 Front Right Coilover Suspension Kit for 2021+ Ford Bronco

Description

Fits:

2021-2025 Ford Bronco

The Bilstein B8 8112 (ZoneControl CR DSA+) is a premium, direct-fit 3-way adjustable coilover engineered for light trucks and SUVs. Designed for both street comfort and off-road performance, it features position-sensitive damping with Dual Speed Adjustability, giving you precise control over your suspension in any condition.

At its core is a triple piston design delivering 3-stage compression and 2-stage rebound damping. The system includes easy-to-use click adjusters for fine-tuning high and low-speed compression, as well as an adjustable internal hydraulic bump stop (JCO) for extra protection during heavy hits. The threaded spring seat allows for 0–3” ride height adjustability (varies by application), and a remote finned aluminum reservoir provides added cooling during extreme use.

Features:

• 3-way adjustable coilover with independent high/low-speed compression and internal bump stop

• Triple piston design for position-sensitive damping

• Ride height adjustable from 0–3” (application-dependent)

• Remote finned aluminum reservoir with anodized chassis mount

• Smooth-body 2.65” aluminum shock body (60mm ID)

• CNC-machined spring seat and hardware

• EVO Grey dampers with black springs

• Requires aftermarket upper control arms

Specifications:

• Collapsed Length: 17.59 in (446.2 mm)

• Extended Length: 23.40 in (594.7 mm)

• Body Diameter: 2.65 in

• Reservoir: Yes (finned aluminum, remote-mounted)

• Finish: EVO Grey (damper), Black (spring)

• Body Material: Aluminum

• Spring Seat: Threaded, included

• Damping Adjustment: Click adjusters for high/low-speed compression + JCO bump stop

• Upper Control Arms Required: Yes

Perfect for those seeking exceptional ride quality on-road and peak suspension performance off-road, the B8 8112 is ready for any terrain.
