Description
This USB Type C 3.1 Power Delivery (PD) cable converts a compatible USB Type C power adapter into a 28V DC power source with up to 5 Amps output through a 5.5mm x 2.1mm center-positive barrel jack.
The cable contains a PD sink negotiation chip that communicates with your USB PD power adapter to request 28V output if supported. Note that the cable does not boost or buck voltage, so a power supply without 28V capability will output a lower voltage such as 20V.
With a length of 1.8 meters, it provides ample reach for your projects and comes with a velcro tie for easy cable management. The connector tip is the most common 5.5mm outer diameter and 2.1mm inner diameter with center positive polarity. If you need center negative polarity, use an optional polarity reversing cable adapter.
Features:
- Converts USB Type C PD power adapter to 28V DC at up to 5A
- Built-in PD sink negotiation chip for voltage communication
- Includes EMARK chip for compliant high current charging
- 1.8 meter cable length with velcro tie
- 5.5mm outer diameter, 2.1mm inner diameter, center positive barrel plug
- Compatible with adapters that support 28V output
Important Note: Ensure your USB PD power supply explicitly supports 28V output; otherwise, a lower voltage will be provided.
