Description
The Teensy++ is a complete USB-based microcontroller development system housed in a compact footprint. Featuring an AVR processor running at 16 MHz, this board requires no special programmer—just a standard Mini-B USB cable and a PC or Macintosh with USB port. This updated 2.0 version offers abundant Flash, RAM, and pins, making it ideal for a wide variety of projects.
- USB can be configured as any type of device
- 16 MHz AVR processor (AT90USB1286) with built-in bootloader
- Single pushbutton programming
- Compatible with Teensy Loader application and free development tools
- Works on Mac OS X, Linux, and Windows
- Compact size for versatile use
- Comes with header pins for easy breadboard integration
The package includes the assembled Teensy++ board and header pins for breadboarding. Recommended software development uses AVR-gcc with LUFA library or Teensyduino. Explore resources at PJRC for full support.
Technical Specifications:
- Dimensions: 2″ x 0.7″
- Flash Memory: 130048 bytes
- RAM: 8192 bytes
- EEPROM: 4096 bytes
- I/O Pins: 46
- ADC: 8 analog inputs (multiplexed to one ADC)
- PWM Outputs: 9
- Interfaces: UART, I2C, SPI hardware
