Slim 24-Pin Flat Flexible Cable Extender with 0.5mm Pitch

Description

This 24-pin FFC / FPC Extender allows you to easily connect two 24-pin 0.5mm pitch Flexible Flat Cables (FFC) or Flexible Printed Circuit (FPC) cables end-to-end to extend their length. It is designed for use with 0.3mm thick FPC cables.

Important: Pin 1 of one cable is connected to pin 24 of the other, so you need to use a cable that has contacts on the same side (type A cable).

Installation involves carefully prying the two ears of the connectors, plugging the cables with contacts pointing up, and then pushing the ears back in for a secure connection.

Available also in 40-pin and 50-pin 0.5mm pitch versions.
