Raspberry Pi Compute Module 4 IO Board

Description

Exposing every interface from Raspberry Pi Compute Module 4, the Compute Module 4 IO Board provides a development platform and reference base-board design for our most powerful Compute Module yet.

Specification

• External power connector (+12V, +5V)
• 2 x full-size HDMI 2.0 connectors
• 2 x USB 2.0 connectors, with header for two additional connectors
• Gigabit Ethernet RJ45 with PoE support
• Micro USB socket for updating Compute Module 4
• MicroSD card socket for Compute Module 4 Lite (without eMMC) variants
• PCIe Gen 2 x1 socket
• Standard fan connector
• 2 x MIPI DSI display FPC connectors (22-pin 0.5 mm pitch cable)
• 2 x MIPI CSI-2 camera FPC connectors (22-pin 0.5 mm pitch cable)
• Standard Raspberry Pi HAT connectors
• Real-time clock with battery socket and ability to wake Compute Module 4
• Various jumpers to disable specific features, e.g. wireless connectivity, EEPROM writing

Documents

• Raspberry Pi Compute Module 4 IO Board product brief
• Raspberry Pi Compute Module 4 IO Board datasheet
• Raspberry Pi Compute Module 4 IO Board KiCAD files

Learning Resources

• Introduction of Raspberry Pi Compute Module 4
• Introduction of Raspberry Pi Compute Module 4 IO Board
• Introduction of Raspberry Pi Compute Module 4 Antenna Kit
