Description
The Kitronik Rear Bike Light Project Kit is an easy-build electronics kit containing just ten parts, making it an excellent introduction to basic electronics. It features two ultra-bright red LEDs that flash rapidly, providing highly visible light ideal for use as a rear bike light, night safety product, or flashing eyes.
Features:
- Easy build kit ideal for beginners in electronics.
- Two ultra-bright red LEDs for excellent visibility at night.
- Compact PCB size of 49mm length and 25mm width.
- Operates on a nominal voltage of 3V with a voltage range of 2-4V.
- Low current consumption of 15mA at nominal voltage.
- Includes a 2xAA battery cage with leads.
Contents:
- 1 x 2xAA Battery Cage with Leads
- 2 x 470K Resistor
- 1 x 33R Resistor
- 2 x Electrolytic Capacitor, 16V, 10uF
- 2 x BC547 NPN Transistor
- 2 x Red 5mm Water Clear LED – 30deg – 1000mCd
Dimensions:
- Length: 48.5mm
- Width: 25.5mm
Requires:
- 2 x AA Batteries
- Soldering Iron
- Solder
- Wire Cutters
Additional Information: This kit is educational and should be used along with a commercially available bike light. A switch can be added for on/off control as shown in the build instructions. Battery life typically lasts about a week with standard AA batteries at 10mA consumption.
Documents & Downloads: Essential Information, Full Teaching Resources, Autodesk Files, 3D CAD Files.
