Kitronik Programmable Night Light Kit with Timer

Description

The Kitronik Timed Night Light Project Kit features a colour-changing LED that turns on when it gets dark and stays lit for a set period. This design helps extend battery life as the light is only on briefly, making it perfect for use as a night light. The kit includes onboard adjustable trimmers to set the light activation threshold and the duration the LED remains on, which can last up to 30 minutes.

• Adjustable light level sensor
• Adjustable length of light time

The kit contains resistors, capacitors, phototransistor, colour-changing LED, battery clips, and the PCB, providing all components needed to build the night light.

Contents:

• 2 x 10K Resistor
• 2 x 1M Resistor
• 1 x PCB trimmer 220K POT
• 1 x PCB trimmer 10M POT
• 1 x 47R Resistor
• 1 x Miniature LDR (phototransistor replacement)
• 1 x Capacitor, Electrolytic, 16V, 470uF
• 4 x 2N7000 N Channel FET
• 1 x Colour Changing 5mm Diffused LED – 750mCd
• 1 x PP3 Battery Clip Lead (Heavy Duty)
• 1 x 3xAA Battery Cage with Clip
• 1 x Timed Night Light Kit PCB

Dimensions: PCB length 53mm, width 41mm.

Requires: 3 x AA Batteries, soldering iron, solder, wire cutters (not included).
