Description
320×480, 3.5 Inch Touch Screen IPS TFT LCD Designed for Raspberry Pi provides a high-resolution display with vibrant colors and wide viewing angles. The IPS technology ensures accurate color reproduction, while the responsive touch interface allows smooth navigation. Compatible with Raspberry Pi 2, 3, 3B, 3B+, and 4, it connects easily via SPI interface. Ideal for DIY projects, gaming, and industrial applications, this compact and durable screen delivers reliable performance.
Features
- 320×480 resolution
- Resistive touch control
- Supports any version of Raspberry Pi (directly-pluggable)
- Drivers provided (works with your own Raspbian/Ubuntu directly)
- IPS technology, high quality and perfect displaying from very wide viewing angle
- Size perfectly fits the Pi
- High-quality immersion gold surface plating
- Supports Raspbian system, enables your system to:
- Take photos by touching (up to 17 camera modes)
- Support software keyboard (system interaction without keyboard/mouse)
Specifications
Key Parameters:
- LCD Type: TFT
- LCD Interface: SPI
- Touch Screen Type: Resistive
- Touch Screen Controller: XPT2046
- Colors: 65536
- Backlight: LED
- Resolution: 320*480 (Pixel)
- Aspect Ratio: 8:5
Interface:
| PIN NO. | SYMBOL | DESCRIPTION |
|---|---|---|
| 1, 17 | 3.3V | Power positive (3.3V power input) |
| 2, 4 | 5V | Power positive (5V power input) |
| 3, 5, 7, 8, 10, 12, 13, 15, 16 | NC | NC |
| 6, 9, 14, 20, 25 | GND | Ground |
| 11 | TP_IRQ | Touch Panel interrupt, low level while the Touch Panel detects touching |
| 18 | LCD_RS | Instruction/Data Register selection |
| 19 | LCD_SI / TP_SI | SPI data input of LCD/Touch Panel |
| 21 | TP_SO | SPI data output of Touch Panel |
| 22 | RST | Reset |
| 23 | LCD_SCK / TP_SCK | SPI clock of LCD/Touch Panel |
| 24 | LCD_CS | LCD chip selection, low active |
| 26 | TP_CS | Touch Panel chip selection, low active |
Kit Content
- 1 x 3.5inch RPi LCD (B)
- 1 x Touch Pen
- 1 x RPi screws pack (2pcs)
- 1 x Quick start sheet
