Description
The Alpha Dual-Gang 25K Audio potentiometer is a two-in-one potentiometer stack designed for independent stereo control. Each half features an audio/log taper 25K potentiometer controlled via a single shared knob. The potentiometer rotates smoothly and maintains firm control without drifting.
Designed with legs spaced 0.2″ apart and featuring pin-point terminals, this potentiometer fits perfboards easily. The shaft is round with a nominal diameter of 6mm (measured approx. 6.3mm). Mounting is easy with the included washer and hex nut for securing into your project enclosure.
Alpha pots are well-regarded for their reliability and quality, making this a cost-effective solution for audio control applications.
Features
- Dual-gang design for stereo control
- Audio/log taper with 25K resistance per half
- Smooth rotary action with firm knob control
- Pin-point terminals spaced 0.2″ apart, perfboard compatible
- Round 6mm diameter shaft
- Includes washer and hex nut for panel mounting
- Reliable, high-quality Alpha brand potentiometer
Technical Details
- Datasheet
- RoHS 2 2011 65 EU Compliant
- RoHS 2 2015 863 EU Compliant
