30cm USB-C to Micro-B Panel-Mount Cable with Male Connectors

Description

This panel mount cable allows you to enclose a device with a USB Micro B port and convert it to a modern USB C connector, perfect for secure project enclosures.

One end features a USB Micro B plug connector, and the other end has a USB C socket with special over-molding. The USB C socket includes two mounting ‘ears’ with M3 screws installed 20mm apart, compatible with box walls up to 0.25″ thick. For thinner walls, shorter M3 screws can be used.

Important: This cable lacks PD resistors and is not compatible with Apple chargers or laptops requiring PD resistors.

• Cable length: 30cm (approximately 12 inches)
• Cable diameter: 4.5mm
• Power wire gauge: 24 AWG
• Data wire gauge: 28 AWG
• Mounting ears with M3 screws, spaced 20mm apart
