Description
The 10.1-inch FHD Touchscreen Display from OKdo is designed for ROCK Single Board Computers (SBCs), delivering a vivid, high-resolution experience. Featuring an active-matrix TFT LCD module with an integrated capacitive touch panel, this display is perfect for a wide range of interactive applications, including:
- Tablets
- Industrial Human-Machine Interfaces (HMIs)
- Informative Dashboards
- Embedded Systems & IoT Projects
With Full HD resolution (1200 x 1920 pixels), wide viewing angles, and MIPI interface compatibility, this touchscreen display ensures a seamless user experience for developers and professionals alike.
Features:
- Panel Size: 10.1 inches
- Compatible with NTSC & PAL systems
- Image Reversion: UP/DOWN and LEFT/RIGHT
- ROHS compliant design
- MIPI electrical interface
- Backlight: White LED
- Pixel arrangement: RGB vertical stripe
Specifications:
- Outline Dimensions: 155(H) x 246.16(V) x 5.95(D) mm
- Display Area: 135.36(H) x 216.58(V) mm
- Resolution: 1200 x 1920 pixels
- Pixel Pitch: 0.0564(H) x 0.1692(V) mm
- Display Mode: Normally Black
- Color Filter Array: RGB vertical stripes
Kit Content:
1x 10.1 Inch FHD Touchscreen Display Only
