Description
Add a bright, hi-res, 1.54″ square LCD screen to your Raspberry Pi or Raspberry Pi Pico projects with this Breakout Garden-compatible SPI display. This vibrant LCD display is around 40% bigger by area than our 1.3″ square breakout, offering plenty of room for detailed graphs, sensor data, or square images like album art. It features an IPS display for great viewing angles, is super-crisp and bright, and can run at up to ~50FPS via SPI interface.
- 1.54″ colour LCD (240×240 pixels)
- SPI interface
- 3.3V or 5V compatible
- Reverse polarity protection
- Compatible with all models of Raspberry Pi (Python library available)
- Compatible with Raspberry Pi Pico (C++/MicroPython libraries)
Specifications:
- Resolution: 240×240 pixels (~220 PPI)
- Active area: 27.72mm x 27.72mm
- Brightness: 250 cd/m²
- Contrast ratio: 900:1
- Viewing angle: 160° horizontal and vertical
- Driver chip: ST7789V
- Dimensions: approx 45mm x 32mm x 5mm
This breakout board can be used solder-free with the Breakout Garden range or wired directly to a Raspberry Pi or Raspberry Pi Pico using the provided male headers. It is ideal for various applications including mini handheld game consoles and projects requiring square displays.
